Single Output Switching Power Supply With Parallel Function (HSCN-1K5-)

Place of Origin:

, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Feature:
1. High reliablility, low ripple noise
2. AC input voltage AC200~260V
3. Protections: Short circuit/over loade/over voltage/over temp. Protection function
4. Built-in remote ON-OFF control and remote sense funciton
5. With parallel function
6. Can adjust from 20%-100% output voltage by external control 1-5V
7. Forced air cooling by built-in DC fan

Remarks:
Custom-made specifications are acceptable.

Specification:

Model		HSCN-1K5-12		HSCN-1K5-15	HSCN-1K5-24		HSCN-1K5-48
Output	DC voltage	12V		15V	24V		48V
	Voltage tolerance	+/-1%		+/-1%	+/-1%		+/-1%
	Rated current	125A		100A	62.5A		32A
	Current range	0-125A		0-100A	0-62.5A		0-32A
	Rated power	1500W		1500W	1500W		1500W
	Ripple & noise	120mVp-p		150mVp-p	240mVp-p		480mVp-p
	DC voltage adj. range	Can adjust from 20%-100% output voltage by external control 1-5V
	Setup, rise, hold time	800ms 50ms 16ms at full load
Input	Voltage range	200~260VAC 290~370VDC 47~63Hz
	AC current	12A/230VAC
	Efficiency	83%	84%			85%	87%
	Inrush current	120A/230V
	Leakage current	3.5Ma/240VDC
Protection	Over load	110~135%
		Protection type: current limiting, delay shut down o/p voltage, re-power on to recover
	Over voltage	110~135%
		Protection type: shut down o/p voltage, re-power on to recover
	Over temperature	TSW1(Power transistor) Temp>100? Shut down o/p voltage, re-power on to recover
Environment	Working temp. & humidity	-10~+65ºC, 20%~90%RH
	Storage temp. & Humidity	-10?~+85ºC, 20%~95%RH
	Vibration	10~200Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z aexs
Safety	Withstand voltage	I/P-O/P, I/P-FG:>1500VAC
	Isolation resistance	I/P-O/P-FG:>100MΩ/500VDC
Standards	Safety standards	Design refer to UL1950, CSA22.2, IEC60950
	EMC standards	Design refer to FCC Part 15 Class A
Others	Weight	4.5kg
	Packing	4pcs/20kg/carton
	Special function	DC voltage adj., remote sensing, remote control, parallel operation
