Feature
The Ultra-Isolation & Noise Suppression Transformer are indoor air self cooling ones, Which is available in the circuit of AC 50Hz and voltage less than 1000V. Input/output voltage of all transformers can be made according to order. Number of phase has three-phase and single-phase, or three-phase input with single-phase/two-phase output etc. The max. Rated power will be up to 1000KVA.
Specification
Phase no.: Three-phase
Input voltage: 360V/380V/400V/415V etc.
Output voltage: 380V
Frequency: 50Hz/60Hz
Ambient temperature: -10 º C ~+40º C
Relative humidity: <95%
Temperature rise: < 60 º C
Withstand voltage: 1500V/min.
Insulation resistance: > 2MΩ
Application
It is available in the electric supplying of electronic instruments, machinery equipment, lighting, rectifying device etc.
Remarks:
Custom-made specifications are acceptable.
Model | Rated power | Pkg size | Qty per pkg(Unit) |
IST-1000VA | 1000VA | 38*25*30 | 1 |
IST-2000VA | 2000VA | 38*25*30 | 1 |
IST-3000VA | 3000VA | 38*25*30 | 1 |
IST-4000VA | 4000VA | 38*25*30 | 1 |
IST-5000VA | 5000VA | 38*25*30 | 1 |
IST-6000VA | 6000VA | 42*30*43 | 1 |
IST-7000VA | 7000VA | 65.8*38*53 | 1 |
IST-8000VA | 8000VA | 65.8*38*53 | 1 |
IST-10KVA | 10KVA | 65.8*38*53 | 1 |
IST-15KVA | 15KVA | 65*41*59 | 1 |
IST-20KVA | 20KVA | 72*44*64 | 1 |
IST-30KVA | 30KVA | 78*49*66 | 1 |
IST-40KVA | 40KVA | 85*51*70 | 1 |
IST-50KVA | 50KVA | 88*53*74 | 1 |
IST-60KVA | 60KVA | 88*53*74 | 1 |
IST-70KVA | 70KVA | 88*53*74 | 1 |
IST-80KVA | 80KVA | 88*53*74 | 1 |
IST-100KVA | 100KVA | 100*70*95 | 1 |
IST-150KVA | 150KVA | 100*70*95 | 1 |
IST-200KVA | 200KVA | 120*80*100 | 1 |
IST-300KVA | 300KVA | 125*90*120 | 1 |
IST-350KVA | 350KVA | 125*90*120 | 1 |
IST-400KVA | 400KVA | 140*105*130 | 1 |
IST-500KVA | 500KVA | 150*110*140 | 1 |
IST-600KVA | 600KVA | 170*110*150 | 1 |
IST-700KVA | 700KVA | 170*110*150 | 1 |
IST-800KVA | 800KVA | 170*120*160 | 1 |
IST-1000KVA | 1000KVA | 190*130*170 | 1 |
